How to replace brake pads on a Toyota Tundra?

Loosen the wheel lug nuts, raise the vehicle and support it securely on jackstands. Block the wheels at the opposite end. Remove the wheels.Remove about two-thirds of the fluid from the master cylinder reservoir and discard it; as the pistons are pushed in to make room for the new pads, the fluid will be forced back into the reservoir. Position a drain pan under the brake assembly and clean the caliper and surrounding area with brake system cleaner (Wash the disc and caliper with brake system cleaner to remove the brake dust; DO NOT blow off the brake dust with compressed air).While the pads are removed, inspect the caliper for brake fluid leaks and ruptures in the piston boot(s). Replace the caliper if it's damaged or leaking. Also inspect the brake disc carefully. If machining is necessary, follow the information in that Section to remove the disc.To replace the front brake pads, (Squeeze the pads towards the caliper frame to free up the pads and depress the pistons into their bores. Detach the pin retaining clip. Pull out the pad retaining pins. Remove the anti-rattle spring. Remove the inner brake pad and push the inner pistons back into their bores to provide room for the new pad. Apply anti-squeal compound to the back of the new pads, then stick the anti-squeal shims to them. Install the new inner pad, then replace the outer pad the same way. Reinstall the pad retaining pins, anti-rattle spring, and the pin retaining clip, then proceed to Step 7). Be sure to stay in order. Work on one brake assembly at a time so you'll have something to refer to if you get in trouble.Using a C-clamp, depress the caliper piston into its bore to make room for the new, thicker pads.To replace the rear brake pads, (Always wash the brakes with brake cleaner before disassembling anything. Using an opened wrench, loosen the lower bolt then remove the mounting bolt or "guide pin". Rotate the caliper up until the upper mounting bolt can be slid out of the bracket. Remove the inner pad and anti-squeal shim. Remove the outer pad and anti-squeal shim. Remove the upper and lower support plates; Inspect them for damage and replace if necessary (if they're weak or distorted, they should be replaced). Install the anti-squeal shims to the brake pads. Install the pads; make sure the ears on the pads are properly engaged with the pad support plates. Install the new inner pad, then the outer pad the same way, and install the caliper over them. Before Installing the caliper mounting bolts, clean and check them for corrosion and damage. If significantly corroded or damaged, replace them. Lubricate the sliding surfaces of the bolts with high-temperature brake grease, install and tighten them, then proceed to Step 7). Be sure to stay in order. Work on one brake assembly at a time so you'll have something to refer to if you get in trouble.Install the brake pads on the opposite wheel, then install the wheels and lower the vehicle. Tighten the lug nuts.Add brake fluid to the reservoir until it's full. Pump the brakes several times to seat the pads against the disc, then check the fluid level again.Check the operation of the brakes before driving the vehicle in traffic. Try to avoid heavy brake applications until the brakes have been applied lightly several times to seat the pads.

Genuine Toyota Tundra Brake Pad Set

Disc Brake Pad Set

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

9 Brake Pad Sets found

View related parts
Toyota Tundra Front Disc Brake Pad Set
Part Number: 04465-35290
$74.93 MSRP: $104.50
You Save: $29.57 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake, Front; Brake Pads, Front Pads
- Manufacturer Note: MARK SUMITOMO PS558H
- Position: Front
- Replaces: 04465-35250
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2000-2006 Toyota Tundra | DLX, Limited, SR5 | 6 Cyl 3.4L, 6 Cyl 4.0L, 8 Cyl 4.7L | 1GRFE, 2UZFE, 5VZFE; 1GRFE, 2UZFE, 5VZFE; GSK30L-ARBSKA, GSK30L-ARFSKA, GSK30L-TRBDKA, GSK30L-TRBDKK, GSK30L-TRFDKA, UCK30L-ARBLKA, UCK30L-ARBSKA, UCK30L-ARBSKK, UCK30L-ARSLKA, UCK30L-ARSLKK, UCK30L-ARSSKA, UCK30L-ARSSKK, UCK30L-ASBLKA, UCK30L-ASBSKA, UCK30L-ASSLKA, UCK30L-ASSSKA, UCK30L-TRBDKA, UCK31L-PRBLKA, UCK31L-PRBSKA, UCK31L-PRBSKK, UCK31L-PRSLKA, UCK31L-PRSSKA, UCK31L-PRSSKK, UCK40L-ARBLKA, UCK40L-ARBLKK, UCK40L-ARBSKA, UCK40L-ARBSKK, UCK40L-ARSLKA, UCK40L-ARSLKK, UCK40L-ARSSKA, UCK40L-ARSSKK, UCK40L-ASBLKA, UCK40L-ASBSKA, UCK40L-ASSLKA, UCK40L-ASSSKA, UCK40L-TRBDKA, UCK40L-TRBDKK, UCK40L-TRSDKK, UCK40L-TRSSKA, UCK41L-PRBLKA, UCK41L-PRBLKK, UCK41L-PRBSKA, UCK41L-PRBSKK, UCK41L-PRSLKA, UCK41L-PRSLKK, UCK41L-PRSSKA, UCK41L-PRSSKK, VCK30L-ARMSKA, VCK30L-ARSLKA, VCK30L-ARSSKA, VCK30L-ARSSKK, VCK30L-TRMDKA, VCK30L-TRMDKK, VCK30L-TRSDKA, VCK30L-TRSDKK, VCK40L-ARMSKA, VCK40L-ARMSKK, VCK40L-ARSLKA, VCK40L-ARSSKA, VCK40L-ARSSKK, VCK40L-TRMDKK, VCK40L-TRMSKA, VCK40L-TRSDKK, VCK40L-TRSSKA
View related parts
Toyota Tundra Front Disc Brake Pad Set
Part Number: 04465-0C020
$74.93 MSRP: $104.50
You Save: $29.57 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake, Front; Brake Pads, Front Pads
- Manufacturer Note: MARK ADVICS PV565H
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2007-2018 Toyota Tundra | Limited, Platinum, SR5 | 6 Cyl 4.0L, 8 Cyl 4.6L, 8 Cyl 4.7L, 8 Cyl 5.7L | 1GRFE, 1URFE, 2UZFE, 3URFBE, 3URFE; 1GRFE, 1URFE, 2UZFE, 3URFBE, 3URFE; GSK50L-TRADKA, GSK51L-CRASKA, GSK51L-THADKA, GSK51L-THASKA, UCK50L-TRADKA, UCK51L-CRALKA, UCK51L-CRASKA, UCK51L-PSALKA, UCK51L-PSASKA, UCK51L-THADKA, UCK52L-CHASKA, UCK55L-TRADKA, UCK56L-CRALKA, UCK56L-CRASKA, UCK56L-PSALKA, UCK56L-PSASKA, UCK56L-THADKA, UCK57L-CHASKA, UPK50L-TRTDKA, UPK51L-CRTLKA, UPK51L-CRTSKA, UPK51L-PSTLKA, UPK51L-PSTSKA, UPK51L-THTDKA, UPK52L-CHTSKA, UPK55L-TRTDKA, UPK56L-CRTLKA, UPK56L-CRTSKA, UPK56L-PSTLKA, UPK56L-PSTSKA, UPK56L-THTDKA, UPK57L-CHTSKA, USK50L-TRTDKA, USK51L-CRTLGA, USK51L-CRTLKA, USK51L-CRTSGA, USK51L-CRTSKA, USK51L-PSTLGA, USK51L-PSTLKA, USK51L-PSTSGA, USK51L-PSTSKA, USK51L-PSTZGA, USK51L-PSTZKA, USK51L-THTDKA, USK51L-THTSGA, USK51L-THTSKA, USK52L-CHTSGA, USK52L-CHTSKA, USK55L-TRTDGA, USK55L-TRTDKA, USK56L-CRTLGA, USK56L-CRTLKA, USK56L-CRTSGA, USK56L-CRTSKA, USK56L-PSTLGA, USK56L-PSTLKA, USK56L-PSTSGA, USK56L-PSTSKA, USK56L-PSTZGA, USK56L-PSTZKA, USK56L-THTDGA, USK56L-THTDKA, USK56L-THTSGA, USK56L-THTSKA, USK57L-CHTSGA, USK57L-CHTSKA
View related parts
Toyota Tundra Rear Disc Brake Pad Set
Part Number: 04466-0C010
$53.55 MSRP: $78.00
You Save: $24.45 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake, Rear; Brake Pads, Rear Pads
- Manufacturer Note: MARK ADVICS PS558H
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2007-2018 Toyota Tundra | Limited, Platinum, SR5 | 6 Cyl 4.0L, 8 Cyl 4.6L, 8 Cyl 4.7L, 8 Cyl 5.7L | 1GRFE, 1URFE, 2UZFE, 3URFBE, 3URFE; 1GRFE, 1URFE, 2UZFE, 3URFBE, 3URFE; GSK50L-TRADKA, GSK51L-CRASKA, GSK51L-THADKA, GSK51L-THASKA, UCK50L-TRADKA, UCK51L-CRALKA, UCK51L-CRASKA, UCK51L-PSALKA, UCK51L-PSASKA, UCK51L-THADKA, UCK52L-CHASKA, UCK55L-TRADKA, UCK56L-CRALKA, UCK56L-CRASKA, UCK56L-PSALKA, UCK56L-PSASKA, UCK56L-THADKA, UCK57L-CHASKA, UPK50L-TRTDKA, UPK51L-CRTLKA, UPK51L-CRTSKA, UPK51L-PSTLKA, UPK51L-PSTSKA, UPK51L-THTDKA, UPK52L-CHTSKA, UPK55L-TRTDKA, UPK56L-CRTLKA, UPK56L-CRTSKA, UPK56L-PSTLKA, UPK56L-PSTSKA, UPK56L-THTDKA, UPK57L-CHTSKA, USK50L-TRTDKA, USK51L-CRTLGA, USK51L-CRTLKA, USK51L-CRTSGA, USK51L-CRTSKA, USK51L-PSTLGA, USK51L-PSTLKA, USK51L-PSTSGA, USK51L-PSTSKA, USK51L-PSTZGA, USK51L-PSTZKA, USK51L-THTDKA, USK51L-THTSGA, USK51L-THTSKA, USK52L-CHTSGA, USK52L-CHTSKA, USK55L-TRTDGA, USK55L-TRTDKA, USK56L-CRTLGA, USK56L-CRTLKA, USK56L-CRTSGA, USK56L-CRTSKA, USK56L-PSTLGA, USK56L-PSTLKA, USK56L-PSTSGA, USK56L-PSTSKA, USK56L-PSTZGA, USK56L-PSTZKA, USK56L-THTDGA, USK56L-THTDKA, USK56L-THTSGA, USK56L-THTSKA, USK57L-CHTSGA, USK57L-CHTSKA
View related parts
Toyota Tundra Disc Brake Pad Kit
Part Number: 04465-02440
$92.70 MSRP: $130.67
You Save: $37.97 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Brake Pads, Front Pads
- Manufacturer Note: MARK ADVICS VC070H
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2017-2021 Toyota Tundra | Limited, Platinum, SR5 | 8 Cyl 4.6L, 8 Cyl 5.7L | 1URFE, 3URFBE, 3URFE; 1URFE, 3URFBE, 3URFE; UPK51L-CRTSKA, UPK51L-PSTSKA, UPK56L-CRTSKA, UPK56L-PSTSKA, USK51L-CRTLKA, USK51L-CRTSKA, USK51L-PSTLKA, USK51L-PSTSKA, USK51L-PSTZKA, USK51L-THTSKA, USK52L-CHTSKA, USK56L-CRTLGA, USK56L-CRTLKA, USK56L-CRTSGA, USK56L-CRTSKA, USK56L-PSTLGA, USK56L-PSTLKA, USK56L-PSTSGA, USK56L-PSTSKA, USK56L-PSTZGA, USK56L-PSTZKA, USK56L-THTSGA, USK56L-THTSKA, USK57L-CHTSGA, USK57L-CHTSKA
View related parts
Toyota Tundra Front Disc Brake Pad Set
Part Number: 04465-0C012
$75.05 MSRP: $102.31
You Save: $27.26 (27%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake, Front; Brake Pads, Front Pads
- Position: Front
- Replaces: 04465-0C011
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2000-2003 Toyota Tundra | DLX, Limited, SR5 | 6 Cyl 3.4L, 8 Cyl 4.7L | 2UZFE, 5VZFE; 2UZFE, 5VZFE; UCK30L-ARSLKA, UCK30L-ARSLKK, UCK30L-ARSSKA, UCK30L-ARSSKK, UCK30L-ASSLKA, UCK30L-ASSSKA, UCK40L-ARSLKA, UCK40L-ARSLKK, UCK40L-ARSSKA, UCK40L-ARSSKK, UCK40L-ASSLKA, UCK40L-ASSSKA, UCK40L-TRSDKK, UCK40L-TRSSKA, VCK30L-ARMSKA, VCK30L-ARSLKA, VCK30L-ARSSKA, VCK30L-ARSSKK, VCK30L-TRMDKA, VCK30L-TRMDKK, VCK30L-TRSDKA, VCK30L-TRSDKK, VCK40L-ARMSKA, VCK40L-ARMSKK, VCK40L-ARSLKA, VCK40L-ARSSKA, VCK40L-ARSSKK, VCK40L-TRMDKK, VCK40L-TRMSKA, VCK40L-TRSDKK, VCK40L-TRSSKA
View related parts
Toyota Tundra Disc Brake Pad Kit
Part Number: 04466-02340
$62.86 MSRP: $88.61
You Save: $25.75 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Brake Pads, Rear Pads
- Manufacturer Note: MARK ADVICS VC071
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2017-2021 Toyota Tundra | Limited, Platinum, SR5 | 8 Cyl 4.6L, 8 Cyl 5.7L | 1URFE, 3URFBE, 3URFE; 1URFE, 3URFBE, 3URFE; UPK51L-CRTSKA, UPK51L-PSTSKA, UPK56L-CRTSKA, UPK56L-PSTSKA, USK51L-CRTLKA, USK51L-CRTSKA, USK51L-PSTLKA, USK51L-PSTSKA, USK51L-PSTZKA, USK51L-THTSKA, USK52L-CHTSKA, USK56L-CRTLGA, USK56L-CRTLKA, USK56L-CRTSGA, USK56L-CRTSKA, USK56L-PSTLGA, USK56L-PSTLKA, USK56L-PSTSGA, USK56L-PSTSKA, USK56L-PSTZGA, USK56L-PSTZKA, USK56L-THTSGA, USK56L-THTSKA, USK57L-CHTSGA, USK57L-CHTSKA
View related parts
Toyota Tundra Front Disc Brake Pad Set
Part Number: 04465-0C011
$75.05 MSRP: $102.31
You Save: $27.26 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake, Front
- Manufacturer Note: CALIPER=TYPE A:REFER TO ILLUSTRATION
- Position: Front
- Replaced by: 04465-0C012
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2000-2001 Toyota Tundra | DLX, Limited, SR5 | 6 Cyl 3.4L, 8 Cyl 4.7L | 2UZFE, 5VZFE; 2UZFE, 5VZFE; UCK30L-ARSLKA, UCK30L-ARSSKA, UCK30L-ARSSKK, UCK40L-ARSLKA, UCK40L-ARSSKA, UCK40L-ARSSKK, UCK40L-TRSSKA, VCK30L-ARMSKA, VCK30L-ARSLKA, VCK30L-ARSSKA, VCK30L-ARSSKK, VCK30L-TRMDKA, VCK30L-TRMDKK, VCK30L-TRSDKA, VCK30L-TRSDKK, VCK40L-ARMSKA, VCK40L-ARMSKK, VCK40L-ARSLKA, VCK40L-ARSSKA, VCK40L-ARSSKK, VCK40L-TRMDKK, VCK40L-TRMSKA, VCK40L-TRSDKK, VCK40L-TRSSKA
View related parts
Toyota Tundra PAD KIT, DISC BRAKE
Part Number: 04466-60190
$61.94 MSRP: $87.31
You Save: $25.37 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Manufacturer Note: MARK ADVICS VC107
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022 Toyota Tundra
View related parts
Toyota Tundra PAD KIT, DISC BRAKE
Part Number: 04465-02580
$96.63 MSRP: $136.22
You Save: $39.59 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Manufacturer Note: MARK ADVICS VC084H
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022 Toyota Tundra

Toyota Tundra Brake Pad Set

The Brake Pad Set of Toyota Tundra pickup are responsible for friction and change of kinetic energy to heat energy thus helping the pickup to stop. These are made from steel backing plates with friction material; they transfer material to the rotor to generate friction for the intended braking. Ideally one or two pads are used per rotor and these are operated by means of a caliper. Brake pads also degenerate with usage and are thus expected to be replaced from time to time Instrumentation is usually provided to notify drivers when this is required. Break pads are categorized depending on the materials used and include Non-Metallic, Semi-Metallic, fully metallic and Ceramic where each of the type was seen to have a unique friction factor, wear rate and Operating Noise factor. The brake pad set of Tundra should be checked or replaced every 50,000 mile so as to keep it on high performance and safety.

If you are in demand for superior quality and affordable OEM Toyota Tundra Brake Pad Set, then shop with us! We own a wide range of the reduced-priced genuine Toyota Tundra Brake Pad Set. You can purchase in confidence as all parts come with a manufacturer's warranty. Any issues with our products? No need to worry as we have a hassle-free return policy to guide you every step of the way.

Toyota Tundra Brake Pad Set Parts Questions & Experts Answers

Front Disc Brake Pad Set
04465-0C020
Q: How to replace brake pads on a Toyota Tundra?
A: Loosen the wheel lug nuts, raise the vehicle and support it securely on jackstands. Block the wheels at the opposite end. Remove the wheels.Remove about two-thirds of the fluid from the master cylinder reservoir and discard it; as the pistons are pushed in to make room for the new pads, the fluid will be forced back into the reservoir. Position a drain pan under the brake assembly and clean the caliper and surrounding area with brake system cleaner (Wash the disc and caliper with brake system cleaner to remove the brake dust; DO NOT blow off the brake dust with compressed air).While the pads are removed, inspect the caliper for brake fluid leaks and ruptures in the piston boot(s). Replace the caliper if it's damaged or leaking. Also inspect the Brake Disc carefully. If machining is necessary, follow the information in that Section to remove the disc.To replace the front brake pads, (Squeeze the pads towards the caliper frame to free up the pads and depress the pistons into their bores. Detach the pin retaining clip. Pull out the pad retaining pins. Remove the anti-rattle spring. Remove the inner brake pad and push the inner pistons back into their bores to provide room for the new pad. Apply anti-squeal compound to the back of the new pads, then stick the anti-squeal shims to them. Install the new inner pad, then replace the outer pad the same way. Reinstall the pad retaining pins, anti-rattle spring, and the pin retaining clip, then proceed to Step 7). Be sure to stay in order. Work on one brake assembly at a time so you'll have something to refer to if you get in trouble.Using a C-clamp, depress the caliper piston into its bore to make room for the new, thicker pads.To replace the rear brake pads, (Always wash the brakes with brake cleaner before disassembling anything. Using an opened wrench, loosen the lower bolt then remove the mounting bolt or "guide pin". Rotate the caliper up until the upper mounting bolt can be slid out of the bracket. Remove the inner pad and anti-squeal shim. Remove the outer pad and anti-squeal shim. Remove the upper and lower support plates; Inspect them for damage and replace if necessary (if they're weak or distorted, they should be replaced). Install the anti-squeal shims to the brake pads. Install the pads; make sure the ears on the pads are properly engaged with the pad support plates. Install the new inner pad, then the outer pad the same way, and install the caliper over them. Before Installing the caliper mounting bolts, clean and check them for corrosion and damage. If significantly corroded or damaged, replace them. Lubricate the sliding surfaces of the bolts with high-temperature brake grease, install and tighten them, then proceed to Step 7). Be sure to stay in order. Work on one brake assembly at a time so you'll have something to refer to if you get in trouble.Install the brake pads on the opposite wheel, then install the wheels and lower the vehicle. Tighten the lug nuts.Add brake fluid to the reservoir until it's full. Pump the brakes several times to seat the pads against the disc, then check the fluid level again.Check the operation of the brakes before driving the vehicle in traffic. Try to avoid heavy brake applications until the brakes have been applied lightly several times to seat the pads.
