Genuine Toyota Yaris Brake Caliper
Caliper- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
8 Brake Calipers found
Toyota Yaris Cylinder Assy, Front Disc Brake, RH
Part Number: 47730-52191$143.31 MSRP: $203.75You Save: $60.44 (30%)Ships in 1-3 Business Days
Toyota Yaris Cylinder Assembly, Disc
Part Number: 47750-12B00$126.28 MSRP: $179.53You Save: $53.25 (30%)Ships in 1-3 Business DaysToyota Yaris Cylinder Assy, Disc Brake, LH
Part Number: 47750-52191$143.31 MSRP: $203.75You Save: $60.44 (30%)Ships in 1-3 Business Days
Toyota Yaris Cylinder Assembly, Disc
Part Number: 47730-WB002$131.13 MSRP: $186.42You Save: $55.29 (30%)Ships in 1-3 Business Days
Toyota Yaris Cylinder Assembly, Disc
Part Number: 47750-WB002$131.13 MSRP: $186.42You Save: $55.29 (30%)Ships in 1-3 Business Days
Toyota Yaris Cylinder Assembly, Disc
Part Number: 47730-12B00$126.28 MSRP: $179.53You Save: $53.25 (30%)Ships in 1-3 Business Days
Toyota Yaris Cylinder Assembly, Disc
Part Number: 47730-52211$130.21 MSRP: $185.12You Save: $54.91 (30%)Ships in 1-3 Business DaysToyota Yaris Cylinder Assembly, Disc
Part Number: 47750-52211$130.21 MSRP: $185.12You Save: $54.91 (30%)Ships in 1-3 Business Days
Toyota Yaris Brake Caliper
If you are in demand for superior quality and affordable OEM Toyota Yaris Brake Caliper, then shop with us! We own a wide range of the reduced-priced genuine Toyota Yaris Brake Caliper. You can purchase in confidence as all parts come with a manufacturer's warranty. Any issues with our products? No need to worry as we have a hassle-free return policy to guide you every step of the way.
Toyota Yaris Brake Caliper Parts Questions & Experts Answers
- Q: How to remove, overhaul, and refit rear brake calipers on Toyota Yaris?A: Chock the front wheels, jack up the rear of the vehicle, and support it on axle stands before removing the rear roadwheels. Fully release the handbrake lever and unscrew the adjustment nut to provide slack in the handbrake cable. Using a screwdriver, press down the handbrake lever on the back of the rear caliper, then disconnect the outer cable from the support bracket by rotating the toothed wheel on the outer cable to release the retaining clip. Clean the area around the caliper brake hose union, unscrew and remove the union bolt, and recover the sealing washer from each side of the hose union, discarding the washers as new ones must be used on refitting. Plug the hose end and caliper hole to minimize fluid loss and prevent dirt ingress into the hydraulic system, then remove the brake pads. If necessary, unbolt the caliper mounting bracket from the trailing arm. Brake calipers have an aluminium cylinder bore that cannot be honed; if scoring is evident, a stainless steel sleeve must be pressed into the cylinder with a new piston used, making overhauling a caliper more expensive than replacing it with a new or re-manufactured one that comes with a warranty. If still intending to overhaul, check on the availability of parts before beginning. Where removed, refit the caliper mounting bracket to the trailing arm, apply locking fluid to the threads of the mounting bolts, insert them, and tighten to the specified torque. Clean the caliper upper swivel pin, apply silicone grease, slide the caliper into its upper guide bearing, and refit the brake pads. Position a new copper sealing washer on each side of the hose union, connect the brake hose to the caliper, ensure correct positioning, then insert the union bolt and tighten it to the specified torque. Remove the brake hose clamp or polythene, and bleed the hydraulic system, noting that it should only be necessary to bleed the relevant rear brake circuit if precautions were taken to minimize brake fluid loss. Refit the handbrake cable to the support bracket and secure it with the retaining clip, press down the handbrake lever, and reconnect the end of the cable. Depress the brake pedal several times to ensure the brake pads are set to their normal position, adjust the handbrake cable, then refit the lever gaiter. Refit the roadwheels, lower the vehicle to the ground, and tighten the roadwheel bolts to the specified torque. Finally, check the brake hydraulic fluid level.
