Toyota 23101-0P020 Fuel Pump Sub-Assembly

You can Select Your Vehicle to check if 23101-0P020 fits your vehicle.

The first step is to ensure that there is enough fuel in the tank.

The initial steps to remove the fuel pump are relieving the fuel system pressure and disconnecting the battery.

Relieve the fuel system pressure and remove the fuel tank cap.

To begin, remove the sending unit assembly from the fuel tank and drain any remaining gasoline from the pump/sending unit. Place the pump/sending unit on a clean workbench in a well-ventilated area. For 2007 and earlier models (except the 2007 RX 350), carefully pry off the end cap from the lower end of the fuel pump/sending unit assembly and remove the rubber insulator from the lower end of the fuel pump. Then, remove the fuel pump inlet strainer by disengaging the locking tabs with a pair of screwdrivers. Disconnect the fuel pressure regulator from the fuel return jet tube hose and fuel filter, and remove the fuel return jet tube assembly by pulling it out of the retainer clip. Disconnect the fuel pump electrical connector and remove the fuel pump from the fuel filter assembly. Separate the fuel filter housing from the upper part of the fuel pump assembly by disengaging the four locking tabs. Detach the fuel level sending unit from the upper part of the fuel pump assembly by disengaging the locking tangs from the lugs on the upper part of the pump.
