Rear Axle Shaft & Hub fit your 2017 Toyota Highlander
Currently shopping for
2017 Toyota Highlander
Change VehicleCategories Close X
Currently selected
Power Train/Chassis
- Brake Band & Multiple Disc Clutch (ATM)
- Brake Booster & Vacuum Tube
- Brake Master Cylinder
- Brake No.3, 1St & Reverse Brake (ATM)
- Brake Pedal & Bracket
- Brake Tube & Clamp
- Center Support & Planetary Sun Gear (ATM)
- Disc Wheel & Wheel Cap
- Front Axle Arm & Steering Knuckle
- Front Axle Housing & Differential
- Front Axle Hub
- Front Disc Brake Caliper & Dust Cover
- Front Drive Shaft
- Front Spring & Shock Absorber
- Front Steering Gear & Link
- Oil Cooler & Tube
- Oil Cooler & Tube (ATM)
- Overdrive Gear (ATM)
- Parking Brake & Cable
- Planetary Gear, Reverse Piston & Counter Gear(ATM)
- Propeller Shaft & Universal Joint
- Rear Axle Housing & Differential
- Rear Axle Shaft & Hub
- Rear Disc Brake Caliper & Dust Cover
- Rear Spring & Shock Absorber
- Shift Lever & Retainer
- Steering Column & Shaft
- Steering Wheel
- Throttle Link & Valve Lever (ATM)
- Torque Converter, Front Oil Pump & Chain (ATM)
- Transaxle Assy
- Transaxle or Transmission Assy & Gasket Kit (ATM)
- Transfer Assembly & Gasket Kit
- Transfer Case & Extension Housing
- Transfer Gear
- Transmission Case & Oil Pan (ATM)
- Valve Body & Oil Strainer (ATM)
Other Categories
Body
Electrical
Engine/Fuel/Tool
Parts Questions
Sort by:
Recommended
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
- Bolt, Hub (For Rear Axle RH)
90942-02049
Bolt, Hub (For Rear Axle RH)- TYPE A:REFER ILLUST.
- Location: Passenger Side
- Require Quantity: 5
- Package Quantity: 10
- Part Name Code: 42311U
- Replaced By: 90942-02082
$5.11 $3.6510
90942-02081
Bolt, Hub (For Rear Axle RH)- TYPE B:REFER ILLUST.
- Location: Passenger Side
- Require Quantity: 5
- Package Quantity: 1
- Part Name Code: 42311U
$5.11 $3.651
90942-02082
Bolt, Hub (For Rear Axle RH)- TYPE C:REFER ILLUST.
- Location: Passenger Side
- Require Quantity: 5
- Package Quantity: 1
- Part Name Code: 42311U
$5.11 $3.651
- Bolt, Hub (For Rear Axle LH)90942-02049
Bolt, Hub (For Rear Axle LH)- TYPE A:REFER ILLUST.
- Location: Driver Side
- Require Quantity: 5
- Package Quantity: 10
- Part Name Code: 42312E
- Replaced By: 90942-02082
$5.11 $3.6510 - 90942-02081
Bolt, Hub (For Rear Axle LH)- TYPE B:REFER ILLUST.
- Location: Driver Side
- Require Quantity: 5
- Package Quantity: 1
- Part Name Code: 42312E
$5.11 $3.651 - 90942-02082
Bolt, Hub (For Rear Axle LH)- TYPE C:REFER ILLUST.
- Location: Driver Side
- Require Quantity: 5
- Package Quantity: 1
- Part Name Code: 42312E
$5.11 $3.651
$98.99 $70.021
$12.76 $9.131
- $12.76 $9.131
47491-22020
Plug, Shoe Adjusting Hole (For Parking Brake)- Require Quantity: 2
- Package Quantity: 1
- Part Name Code: 42491
$4.28 $3.061
- Hub & Bearing Assy, Rear Axle, RH
42450-0E050
Hub & Bearing Assy, Rear Axle, RH- Location: Passenger Side
- Fitting Vehicle Options: ASU50, GSU50
- Part Name Code: 42450A
$619.75 $421.031
42410-0E031
Hub & Bearing Assy, Rear Axle, RH- Location: Passenger Side
- Fitting Vehicle Options: GSU55, GVU58
- Part Name Code: 42410
$381.97 $266.381
- Hub & Bearing Assy, Rear Axle, LH42450-0E050
Hub & Bearing Assy, Rear Axle, LH- Location: Driver Side
- Fitting Vehicle Options: ASU50, GSU50
- Part Name Code: 42450B
$619.75 $421.031 - 42410-0E031
Hub & Bearing Assy, Rear Axle, LH- Location: Driver Side
- Fitting Vehicle Options: GSU55, GVU58
- Part Name Code: 42440
$381.97 $266.381
- Boot Kit, Rear Drive Shaft, In & Outboard Joint, RH
04429-0E010
Boot Kit, Rear Drive Shaft, In & Outboard Joint, RH- Location: Passenger Side
- Production Date: 12/2013-07/2017
- Fitting Vehicle Options: GSU55
- Part Name Code: 04438N
- Replaced By: 04429-0E011
$89.47 $63.471 - 04429-0E011
Boot Kit, Rear Drive Shaft, In & Outboard Joint, RH- Location: Passenger Side
- Production Date: from 07/2017
- Fitting Vehicle Options: GSU55
- Part Name Code: 04438N
$89.47 $63.471 - 04429-0T021
Boot Kit, Rear Drive Shaft, In & Outboard Joint, RH- Location: Passenger Side
- Production Date: 01/2014-12/2016
- Fitting Vehicle Options: GVU58
- Part Name Code: 04438N
$89.47 $63.471 - 04429-0T023
Boot Kit, Rear Drive Shaft, In & Outboard Joint, RH- Location: Passenger Side
- Production Date: from 12/2016
- Fitting Vehicle Options: GVU58
- Part Name Code: 04438N
$89.59 $63.551
- Boot Kit, Rear Drive Shaft, In & Outboard Joint, LH
04429-0E010
Boot Kit, Rear Drive Shaft, In & Outboard Joint, LH- Location: Driver Side
- Production Date: 12/2013-07/2017
- Fitting Vehicle Options: GSU55
- Part Name Code: 04438Q
- Replaced By: 04429-0E011
$89.47 $63.471 - 04429-0E011
Boot Kit, Rear Drive Shaft, In & Outboard Joint, LH- Location: Driver Side
- Production Date: from 07/2017
- Fitting Vehicle Options: GSU55
- Part Name Code: 04438Q
$89.47 $63.471 - 04429-0T021
Boot Kit, Rear Drive Shaft, In & Outboard Joint, LH- Location: Driver Side
- Production Date: 01/2014-12/2016
- Fitting Vehicle Options: GVU58
- Part Name Code: 04438Q
$89.47 $63.471 - 04429-0T023
Boot Kit, Rear Drive Shaft, In & Outboard Joint, LH- Location: Driver Side
- Production Date: from 12/2016
- Fitting Vehicle Options: GVU58
- Part Name Code: 04438Q
$89.59 $63.551
$44.42 $31.781
04439-0T012
Boot Kit, Rear Drive Shaft Inboard Joint, RH- Location: Passenger Side
- Part Name Code: 04437C
$44.42 $31.781
- $44.42 $31.781
- Shaft Assy, Rear Drive, RH
42340-0E050
Shaft Assy, Rear Drive, RH- Location: Passenger Side
- Fitting Vehicle Options: GSU55
- Part Name Code: 42330
$504.77 $342.911
42340-0E070
Shaft Assy, Rear Drive, RH- Location: Passenger Side
- Production Date: 01/2014-02/2017
- Fitting Vehicle Options: GVU58
- Part Name Code: 42330
$493.10 $343.881- 42340-0E071
Shaft Assy, Rear Drive, RH- Location: Passenger Side
- Production Date: from 02/2017
- Fitting Vehicle Options: GVU58
- Part Name Code: 42330
$493.10 $343.881
- Shaft Assy, Rear Drive, LH
42340-0E060
Shaft Assy, Rear Drive, LH- Location: Driver Side
- Fitting Vehicle Options: GSU55
- Part Name Code: 42340B
$504.77 $342.911 - 42340-0E070
Shaft Assy, Rear Drive, LH- Location: Driver Side
- Production Date: 01/2014-02/2017
- Fitting Vehicle Options: GVU58
- Part Name Code: 42340B
$493.10 $343.881 - 42340-0E071
Shaft Assy, Rear Drive, LH- Location: Driver Side
- Production Date: from 02/2017
- Fitting Vehicle Options: GVU58
- Part Name Code: 42340B
$493.10 $343.881
- Clamp (For Rear Drive Shaft Inboard Joint Boot)
42345-0E060
Clamp (For Rear Drive Shaft Inboard Joint Boot)- ID=75.8
- Fitting Vehicle Options: GSU55
- Part Name Code: 42347A
$7.18 $5.141 - 42345-0T010
Clamp (For Rear Drive Shaft Inboard Joint Boot)- ID=74.9
- Fitting Vehicle Options: GVU58
- Part Name Code: 42347A
$8.13 $5.821
- Clamp, NO.2 (For Rear Drive Shaft Inboard Joint Boot)
42345-0E070
Clamp, NO.2 (For Rear Drive Shaft Inboard Joint Boot)- Fitting Vehicle Options: GSU55
- Part Name Code: 42347B
$3.19 $2.281 - 42345-0T020
Clamp, NO.2 (For Rear Drive Shaft Inboard Joint Boot)- Fitting Vehicle Options: GVU58
- Part Name Code: 42347B
$3.76 $2.691
- Clamp, NO. 2 (For Rear Drive Shaft Outboard Joint Boot)
42345-0E080
Clamp, NO. 2 (For Rear Drive Shaft Outboard Joint Boot)- Fitting Vehicle Options: GSU55
- Part Name Code: 42346B
$9.68 $6.931 - 42345-0T030
Clamp, NO. 2 (For Rear Drive Shaft Outboard Joint Boot)- Fitting Vehicle Options: GVU58
- Part Name Code: 42346B
$8.91 $6.371
- Clamp (For Rear Drive Shaft Outboard Joint Boot)
42345-0E090
Clamp (For Rear Drive Shaft Outboard Joint Boot)- ID=25.3
- Fitting Vehicle Options: GSU55
- Part Name Code: 42346A
$8.02 $5.741 - 42345-0E370
Clamp (For Rear Drive Shaft Outboard Joint Boot)- Fitting Vehicle Options: GVU58
- Part Name Code: 42346A
$7.90 $5.651 - 42345-0T040
Clamp (For Rear Drive Shaft Outboard Joint Boot)- ID=29.0
- Fitting Vehicle Options: GVU58
- Part Name Code: 42346A
$7.27 $5.201
- Ring, Shaft Snap (For Rear Drive Shaft Inboard Joint)
43425-0E050
Ring, Shaft Snap (For Rear Drive Shaft Inboard Joint)- Fitting Vehicle Options: GSU55
- Part Name Code: 42360A
$0.52 $0.371 - 43425-0T030
Ring, Shaft Snap (For Rear Drive Shaft Inboard Joint)- Fitting Vehicle Options: GVU58
- Part Name Code: 42360A
$1.81 $1.301
$0.43 $0.311
- Ring, Snap (For Rear Drive Shaft Inboard Joint)43425-0E070
Ring, Snap (For Rear Drive Shaft Inboard Joint)- Fitting Vehicle Options: GSU55
- Part Name Code: 42360B
$0.78 $0.561
43425-0T020
Ring, Snap (For Rear Drive Shaft Inboard Joint)- Fitting Vehicle Options: GVU58
- Part Name Code: 42360B
$1.44 $1.021
90105-14097
Bolt (For Rear Axle Bearing Case RH)- Location: Passenger Side
- Require Quantity: 4
- Package Quantity: 1
- Part Name Code: 42421E
$6.38 $4.561
- 90105-14097
Bolt (For Rear Axle Bearing Case LH)- Location: Driver Side
- Require Quantity: 4
- Package Quantity: 1
- Part Name Code: 42422A
$6.38 $4.561
90311-42047
Oil Seal, Rear Drive Shaft, RH- Location: Passenger Side
- Part Name Code: 42330G
- Replaced By: 90311-42062
$21.43 $15.341
- 90311-42047
Oil Seal, Rear Drive Shaft, LH- Location: Driver Side
- Part Name Code: 42340D
- Replaced By: 90311-42062
$21.43 $15.341
$2.04 $1.461
$1.64 $1.171
Genuine Toyota Parts, the Right Choice
ToyotaPartsDeal.com offers the wholesale prices for genuine 2017 Toyota Highlander parts. Parts like Rear Axle Shaft & Hub are shipped directly from authorized Toyota dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 2.7L, 6 Cyl 3.5L.
