How to remove and install the fuel pump/fuel level sending unit assembly on 2002 through 2006 Toyota Avalon?

Relieve the fuel system pressure, then disconnect the negative battery cable. Remove the fuel pump/fuel level sending unit assembly from the fuel tank. Carefully angle the sending unit out of the opening without damaging the fuel level float located at the bottom of the assembly. Disconnect the electrical connector from the sending unit. Pry the sending unit from the retaining clips. Disconnect the electrical connector and pry the fuel level sending unit from the clips and separate it from the assembly. Installation is the reverse of removal.

How to check, remove, and install the fuel level sending unit on 1997 through 2001 Toyota Avalon?

To check the fuel level sensor, relieve fuel system pressure and disconnect the negative battery cable. Remove the fuel pump/fuel level sensor from the fuel tank. Disconnect the sensor connector and use an ohmmeter to check resistance while moving the float arm. Resistance should be around 110-115 ohms when the tank is empty and 2-3 ohms when full, with a smooth transition in between. If readings are incorrect, replace the sensor. For removal, carefully angle the sensor out of the opening without damaging the fuel level float and disconnect electrical connectors. Remove mounting screws and separate the sensor from the assembly. Installation is the reverse of removal.

How to remove and install a fuel pump and Fuel Level Sensor on 2007 through 2015 Toyota Avalon?

For fuel pump removal, start by relieving the fuel system pressure and disconnecting the battery cable. Remove the rear seat cushion, then carefully pry up the fuel pump module/Fuel Level Sensor access cover. Disconnect the electrical connector(s) and fuel line from the top of the fuel pump unit, using a small screwdriver to release the yellow clip on the fuel line. Remove the retaining bolts of the fuel pump module/Fuel Level Sensor and carefully withdraw it from the fuel tank. If dealing with a Fuel Level Sensor, disconnect its electrical connector and slide it out after releasing the plastic locking tab. For fuel pump module removal on four-cylinder models (2011 and earlier), disconnect the fuel pump electrical connector from the fuel suction plate. Use needle-nose pliers to remove the spring E-clip, disengage suction support mounting clips, and separate the band bracket from the fuel filter assembly. Do not disconnect the fuel tube line between the suction plate and top plate to avoid damage. Remove the spring, disengage clips from the fuel suction support, and separate the support from the fuel pump. Pull out the fuel pump from the filter assembly, disconnect and remove the fuel pump electrical harness, disengage the clips securing the inlet strainer to the pump, and inspect the strainer for contamination. On V6 models and 2012 and later 4-cylinder models, pry the sub-tank from the assembly, remove the rubber cushion, disconnect the fuel pump electrical connector, disengage the fuel suction plate mounting clips, disconnect and remove the fuel pump electrical harness, pull the fuel pump out from the filter assembly, remove the clip securing the inlet strainer, and inspect it for contamination. For installation, reassemble the fuel pump module in reverse order and install the fuel pump/sending unit assembly in the tank, connecting the fuel line and electrical connector. Finish the installation as outlined in the removal process.

Genuine Toyota Avalon Fuel Level Sensor

Gas Gauge Sensor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

16 Fuel Level Sensors found

View related parts
Toyota Avalon Gage Assy, Fuel Sender
Part Number: 83320-33030
$166.49 MSRP: $236.70
You Save: $70.21 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Gauge Unit, Sending Unit
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1997-1999 Toyota Avalon | XL, XLS | 6 Cyl 3.0L | 1MZFE; 1MZFE; MCX10L-AEPGKA, MCX10L-AEPGKK, MCX10L-AEPNKA, MCX10L-AEPNKK, MCX10L-AESGKA, MCX10L-AESGKK, MCX10L-AESNKA, MCX10L-AESNKK
View related parts
Toyota Avalon Gage Assembly, Fuel Send
Part Number: 83320-06121
$73.97 MSRP: $104.27
You Save: $30.30 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Gage Assy, Fuel Sender
- Replaces: 83320-06120
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2013-2018 Toyota Avalon | Limited, XLE, XLE Premium, XLE Touring Or Touring | 4 Cyl 2.5L, 6 Cyl 3.5L | 2ARFXE, 2GRFE; 2ARFXE, 2GRFE; AVX40L-AEXGBA, AVX40L-AEXPBA, GSX40L-AETGKA, GSX40L-AETPKA, GSX40L-AETQKA
View related parts
Toyota Avalon Sensor, Fuel PRESSUR
Part Number: 89458-06021
$153.38 MSRP: $218.05
You Save: $64.67 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Pressure Regulator, Pressure Sensor
- Manufacturer Note: (L)
- Replaces: 89458-33041
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2019-2022 Toyota Avalon | Limited, XLE, XSE | 4 Cyl 2.5L | A25AFKS, A25AFXS; A25AFKS, A25AFKS; AXXA55L-AEZGBA, A25AFXS; AXXA55L-AEZGBA, AXXA55L-AEZPBA, AXXH50L-AEXGBA, AXXH50L-AEXPBA, AXXH50L-AEXQBA, AXXH51L-AEXGBA, AXXH51L-AEXPBA, AXXH51L-AEXQBA
View related parts
Toyota Avalon Gage Assy, Fuel Sender
Part Number: 83320-49075
$166.49 MSRP: $236.70
You Save: $70.21 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Sending Unit
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1996-1998 Toyota Avalon | XL, XLS | 6 Cyl 3.0L | 1MZFE; 1MZFE; MCX10L-AEPGKA, MCX10L-AEPGKK, MCX10L-AEPNKA, MCX10L-AEPNKK, MCX10L-AESGKA, MCX10L-AESGKK, MCX10L-AESNKA, MCX10L-AESNKK
View related parts
Toyota Avalon Gage Assy, Fuel Sender
Part Number: 83320-33070
$93.01 MSRP: $131.11
You Save: $38.10 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Manufacturer Note: (J)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2004 Toyota Avalon | XL, XLS | 6 Cyl 3.0L | 1MZFE; 1MZFE; MCX20L-AEPGKA, MCX20L-AEPGKK, MCX20L-AEPNKA, MCX20L-AEPNKK, MCX20L-AESGKA, MCX20L-AESNKA
View related parts
Toyota Avalon Gage Assy, Fuel Sender
Part Number: 83320-80204
$188.62 MSRP: $270.46
You Save: $81.84 (31%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Gauge, Sending Unit
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1995-1997 Toyota Avalon | XL, XLS | 6 Cyl 3.0L | 1MZFE; 1MZFE; MCX10L-AEPGKA, MCX10L-AEPGKK, MCX10L-AEPNKA, MCX10L-AEPNKK, MCX10L-AESGKA, MCX10L-AESGKK, MCX10L-AESNKA, MCX10L-AESNKK
View related parts
Toyota Avalon Gage Assy, Fuel Sender
Part Number: 83320-07010
$81.35 MSRP: $114.67
You Save: $33.32 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2005-2012 Toyota Avalon | Limited, XL, XLS | 6 Cyl 3.5L | 2GRFE; 2GRFE; GSX30L-AEAGKA, GSX30L-AEANKA, GSX30L-AEAPKA, GSX30L-AETGKA, GSX30L-AETNKA, GSX30L-AETPKA
View related parts
Toyota Avalon Gage Assy, Fuel Sender
Part Number: 83320-41020
$93.62 MSRP: $131.97
You Save: $38.35 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Sending Unit
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2000-2002 Toyota Avalon | XL, XLS | 6 Cyl 3.0L | 1MZFE; 1MZFE; MCX20L-AEPGKA, MCX20L-AEPGKK, MCX20L-AEPNKA, MCX20L-AEPNKK, MCX20L-AESGKA, MCX20L-AESNKA
View related parts
Toyota Avalon Gage Assembly, Fuel Send
Part Number: 83320-06120
$73.97 MSRP: $104.27
You Save: $30.30 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Gage Assy, Fuel Sender
- Replaced by: 83320-06121
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2013-2015 Toyota Avalon | Limited, XLE, XLE Premium, XLE Touring Or Touring | 4 Cyl 2.5L, 6 Cyl 3.5L | 2ARFXE, 2GRFE; 2ARFXE, 2GRFE; AVX40L-AEXGBA, AVX40L-AEXPBA, GSX40L-AETGKA, GSX40L-AETPKA, GSX40L-AETQKA
View related parts
Toyota Avalon Sensor, Fuel PRESSUR
Part Number: 89458-33041
$153.38 MSRP: $218.05
You Save: $64.67 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Manufacturer Note: (J)
- Replaced by: 89458-06021
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2022 Toyota Avalon | Limited, XLE | 4 Cyl 2.5L | A25AFKS; A25AFKS; AXXA55L-AEZGBA, AXXA55L-AEZPBA
View related parts
Toyota Avalon Gage Assembly, Fuel Send
Part Number: 83320-06140
$70.92 MSRP: $99.96
You Save: $29.04 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Level Sensor
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2019-2022 Toyota Avalon | Limited, Touring, XSE | 6 Cyl 3.5L | 2GRFKS; 2GRFKS; GSX50L-AEZPBA, GSX50L-AEZQBA, GSX50L-AEZSBA
View related parts
Toyota Avalon Gage Assembly, Fuel Send
Part Number: 83320-06180
$70.92 MSRP: $99.96
You Save: $29.04 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Level Sensor
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2019-2022 Toyota Avalon | XLE | 6 Cyl 3.5L | 2GRFKS; 2GRFKS; GSX50L-AEZGBA
View related parts
Toyota Avalon Gage Assembly, Fuel Send
Part Number: 83320-06190
$70.92 MSRP: $99.96
You Save: $29.04 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Level Sensor
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2022 Toyota Avalon | Limited, XLE | 4 Cyl 2.5L | A25AFKS; A25AFKS; AXXA55L-AEZGBA, AXXA55L-AEZPBA
View related parts
Toyota Avalon Gage Assembly, Fuel Send
Part Number: 83320-06200
$70.92 MSRP: $99.96
You Save: $29.04 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2022 Toyota Avalon | Limited, XLE | 4 Cyl 2.5L | A25AFKS; A25AFKS; AXXA55L-AEZGBA, AXXA55L-AEZPBA
View related parts
Toyota Avalon Gage Assembly, Fuel Send
Part Number: 83320-33160
$70.92 MSRP: $99.96
You Save: $29.04 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Gauge Sending Unit, Level Sensor
- Manufacturer Note: MARK=33160
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2019-2022 Toyota Avalon | Limited, XLE, XSE | 4 Cyl 2.5L | A25AFXS; A25AFXS; AXXH50L-AEXGBA, AXXH50L-AEXPBA, AXXH50L-AEXQBA, AXXH51L-AEXGBA, AXXH51L-AEXPBA, AXXH51L-AEXQBA
View related parts
Toyota Avalon Gage Assy, Fuel Sender
Part Number: 83320-06010
Product Specifications
- Manufacturer Note: (L)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2002-2004 Toyota Avalon | XL, XLS | 6 Cyl 3.0L | 1MZFE; 1MZFE; MCX20L-AEPGKA, MCX20L-AEPGKK, MCX20L-AEPNKA, MCX20L-AEPNKK, MCX20L-AESGKA, MCX20L-AESNKA

Toyota Avalon Fuel Level Sensor

The Fuel Level Sensor is another component with Toyota Avalon cars it is used to enable the driver to be informed of the level of fuel in the tank. The mentioned electronic devices are intended to give the driver precise information on fuel amounts as they are immune to high temperatures. The sensor is made up of mainly of a float, actuating rod as well as a resistor through which a signal is passed to the fuel indicator. As for the examined scheme, if any problems occur with the fuel level sensor, they recommend performing car maintenance to obtain accurate data and avoid low fuel remaining notice delays.

If you are in demand for superior quality and affordable OEM Toyota Avalon Fuel Level Sensor, then shop with us! We own a wide range of the reduced-priced genuine Toyota Avalon Fuel Level Sensor. You can purchase in confidence as all parts come with a manufacturer's warranty. Any issues with our products? No need to worry as we have a hassle-free return policy to guide you every step of the way.

Toyota Avalon Fuel Level Sensor Parts Questions & Experts Answers

Gage Assy, Fuel Sender
83320-07010
Q: How to remove and install the fuel pump/fuel level sending unit assembly on 2002 through 2006 Toyota Avalon?
A: Relieve the fuel system pressure, then disconnect the negative battery cable. Remove the Fuel Pump/fuel level sending unit assembly from the Fuel Tank. Carefully angle the sending unit out of the opening without damaging the fuel level float located at the bottom of the assembly. Disconnect the electrical connector from the sending unit. Pry the sending unit from the retaining clips. Disconnect the electrical connector and pry the fuel level sending unit from the clips and separate it from the assembly. Installation is the reverse of removal.
Gage Assy, Fuel Sender
83320-41020
Q: How to check, remove, and install the fuel level sending unit on 1997 through 2001 Toyota Avalon?
A: To check the fuel level sensor, relieve fuel system pressure and disconnect the negative battery cable. Remove the Fuel Pump/fuel level sensor from the Fuel Tank. Disconnect the sensor connector and use an ohmmeter to check resistance while moving the float arm. Resistance should be around 110-115 ohms when the tank is empty and 2-3 ohms when full, with a smooth transition in between. If readings are incorrect, replace the sensor. For removal, carefully angle the sensor out of the opening without damaging the fuel level float and disconnect electrical connectors. Remove mounting screws and separate the sensor from the assembly. Installation is the reverse of removal.
Gage Assembly, Fuel Send
83320-06121
Q: How to remove and install a fuel pump and Fuel Level Sensor on 2007 through 2015 Toyota Avalon?
A: For fuel pump removal, start by relieving the fuel system pressure and disconnecting the battery cable. Remove the rear seat cushion, then carefully pry up the fuel pump module/Fuel Level Sensor access cover. Disconnect the electrical connector(s) and fuel line from the top of the fuel pump unit, using a small screwdriver to release the yellow clip on the fuel line. Remove the retaining bolts of the fuel pump module/Fuel Level Sensor and carefully withdraw it from the Fuel Tank. If dealing with a Fuel Level Sensor, disconnect its electrical connector and slide it out after releasing the plastic locking tab. For fuel pump module removal on four-cylinder models (2011 and earlier), disconnect the fuel pump electrical connector from the fuel suction plate. Use needle-nose pliers to remove the spring E-clip, disengage suction support mounting clips, and separate the band bracket from the fuel filter assembly. Do not disconnect the fuel tube line between the suction plate and top plate to avoid damage. Remove the spring, disengage clips from the fuel suction support, and separate the support from the fuel pump. Pull out the fuel pump from the filter assembly, disconnect and remove the fuel pump electrical harness, disengage the clips securing the inlet strainer to the pump, and inspect the strainer for contamination. On V6 models and 2012 and later 4-cylinder models, pry the sub-tank from the assembly, remove the rubber cushion, disconnect the fuel pump electrical connector, disengage the fuel suction plate mounting clips, disconnect and remove the fuel pump electrical harness, pull the fuel pump out from the filter assembly, remove the clip securing the inlet strainer, and inspect it for contamination. For installation, reassemble the fuel pump module in reverse order and install the fuel pump/sending unit assembly in the tank, connecting the fuel line and electrical connector. Finish the installation as outlined in the removal process.
